The TSL 2128-AX0 Standard Range UHF Mobile RFID Sled introduces the revolutionary, patented TSL ePop-Loq connector system enabling data and charging connections to be passed from the reader to an attached device, such as a smartphone or handheld terminal. The unique ePop-Loq system is also designed to safely separate when the reader is subject to large impacts, such as when dropped.
The 2128 UHF RFID Sled supports both Bluetooth Classic as well as Bluetooth Low Energy (BLE). The reader can be operated in a Serial Port Profile (SPP) or in a Human Interface Device mode (HID), as well as supporting iApp2 for Apple iOS devices. The reader also supports an automatic re-connect mode for both Android and Apple devices.
What's Included:
- TSL 2128 Standard Range RFID Sled
- 2400 mAh Lithium Polymer Battery
Note: The TSL 2128 RFID Sled DOES NOT HAVE A BARCODE SCANNER.
- Frequency Range US: 902-928MHz; 0 - 30 dBm (region dependant)+ 3.0 dBiC Antenna
- Standards Supported: EPC Class 1 Gen 2
- Nominal Read Range: ~19.6+ ft / ~6+ m
- Detachable, Right Hand Circularly Polarized Antenna
- 150-degree forward facing Read Field
- Dimensions: 6.3 in. H x 3.0 in. W x 2.5 in. L
- Weight: 12.8oz / 365g
- Drop Spec: Multiple drops to concrete: 4 ft./1.2 m ambient, 3ft / 0.9m across the operating temperature range, IP54 Sealing
- Bluetooth Version 4.2, USB connection to handheld terminal via ePop-Loq cases (separate purchase)
2128 Spec Sheet
Your TSL 2128 mobile RFID reader is warrantied against defects in workmanship and materials for a period of one year (12 months) from date of shipment, provided the product remains unmodified and is operated under normal and proper conditions.
What devices does the 2128 RFID Sled work with?
The 2128 currently supports the Zebra TC20/TC25, TC52/TC57, and Janam XT30/XT40 with the ePop-Loq adapter case along with most Android and iOS devices using a Bluetooth Connection.
What is needed to use the TSL 2128 sled to read RFID tags?
You will need a compatible device as mentioned above and software that is capable of collecting and storing RFID data.
TracerPlus is RFID enabled data collection software allowing you to create RFID ready applications in minutes.
2128 Quick Start Guide
2128 User Guide
